OD17mm Formwork Tie Rod

OD17mm Formwork Tie Rod
OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod OD17mm Formwork Tie Rod

Large Image :  OD17mm Formwork Tie Rod

Product Details:

Place of Origin: Hebei, China (Mainland)
Brand Name: WST
Model Number: WSTFTR

Payment & Shipping Terms:

Packaging Details: 1. woven films 2. pallet 3. Customized
Delivery Time: 7-25 days
Supply Ability: 10 Ton/Tons per Day
Detailed Product Description
Material: Q235 Or 45#steel Diameter: 17MM
Weight: 1.5kg Length: 1-6M/PC
Finish: Natural , Electro Galvanized,HDG HS Code: 7308400000
Application: Building Construction Material Grade: PSB830
Color: Natural, White Galvanized, Colorful Galvanized Color Product Name: Hot Rolled Formwork 16mm Tie Rod
Craft: Hot Rolled Screw Pitch: 10mm
Surface Treatment: Natural, Electro Galvanized,HDG Breaking Load: More Than 180KN






Tie rod types 12mm Tie Rod 17mm Tie Rod 20mm Tie Rod Hot Rolled Tie Rod
Pics OD17mm Formwork Tie Rod 1 OD17mm Formwork Tie Rod 2 OD17mm Formwork Tie Rod 3 OD17mm Formwork Tie Rod 4
Material 45# steel /Q235 steel PSB830 Grade
Diameter(mm) 10/12 15/17 18.8/21,20/22,21/23 15/17
Pitch(mm) 4 10/6.35 10 10
Length(M/PC) 0-6 0-6 0-6 0-6
Weight(kg) 0.72 1.5 2.5 1.47
Finish Self color(Black),Electro Glvanized
Color Black,Silver,Yellow

Tensile

Strength(KN)

50-65

45# ,140-150

Q235 ,90-100

230-245 180-190



Related Product


OD17mm Formwork Tie Rod 5

Packaging & Shipping


OD17mm Formwork Tie Rod 6



Certifications




OD17mm Formwork Tie Rod 7



Buyer Feedback


customer feedback_

FAQ


1. Q: Are you real factory ?
A: Yes, we are direct factory and we have our own casting iron factory . we have 3 factories established on 2010.

2. Q: Do you have customers in our country ?
A: Not sure, Our 100+ customers are from 30+ countries, including Thailand, Singapore, Russian, Korea,USA,UK,Norway,UAE ,Bangladesh etc, Just contact us to confirm and experience our service and product directly.

3. Q: How about your production and export amount ?
A: 19000T/year, about 70*20ft container per month.

4. Q: How about the price?
A: High cost -effective .
First, we are near the origin of steel ,with big order amount, we get relatively cheaper price of steel raw material ;
Second,we have our own inspection regulation and system,from the raw material to the the finished products, quality is ensured
Third, our professional and responsible service have got good feedbacks from our customers.
Forth, "less profit but big turnover " is our perpetual business principle.

5. Q: How can we ensure the quality ?
A : First, Only qualified raw material with certification is acceptable.
Second,quality check is operated by hand.
Three, free samples are always available.
Fourth,once quality problems occur, just sent us pics for confirmation,
once confirmed, money or goods will be given as compensation.

6. Q: Where are your factory located, how can we go to your factory ?
A : We are in Botou, Cangzhou ,Hebei province, the hometown of casting products.
Take high speed trains to Cangzhou Station, or take plane to Tianjin airport or Beijing airport, then we could go to pick you up. From cangzhou station to our factory, it will cost 30mins; from Tianjin or Beijing Airport to our factory, it will cost about 3-4hours.

Welcome to visit us at any time!
